SPINDLE BORE ø152 ; ø230 ; ø255; ø305; ø380mm DHL & DHK Series
DHL Series WIDTH OF BED 24" (610mm)
DHL-960/1120/1220~1420 x1500;2000;3000;4000;5000;6000
DHK Series WIDTH OF BED 32" (810mm)
DHK-960/1120/1220~1620 x2000;3000;4000;5000;6000
產品介紹
重型CNC車床 DHL&DHK Series
SPINDLE BORE : 6” , 9” , 10”, 12”, 15”
Spindle bore 9" , 10", 12", 15" only fit to swing over bed over 1120mm.
BED WIDTH : 24” (DHL series), 32” (DHK series)
One-piece casting base for processing capacity to be more stable.
- This is a heavy duty precision CNC lathe that has the function of output full horse power during low & high speed, available for big, special parts and mold work pieces.
- The structure of bed is adopted high toughness Meehanite cast iron; stabilize properly parallel precision, bed ways are induction hardened and ground.
- The slide way and ball screw can be lubricated automatically by central lubrication system. Oil flow and lubrication frequency can be set as desired. An alarm occurs in case of lack of oil.
- The coolant system delivers high pressure coolant to flush chips and extend tool service life.
- Mechanical and electrical are designed all in one.
◆ We reseve the right for changing the shape of splash guard.
